APC Back-UPS, 500VA/300W, Tower, 230V, AVR, LED (BR500CI-AS)

    150,000

    Mã hàng: BR500CI-AS

    Thông tin nhanh về sản phẩm

    BR500CI-AS
    APC Back-UPS, 500VA/300W, Tower, 230V, 3x IEC C13 outlets, AVR, LED, User Replaceable Battery

    UPS ĐÃ QUA SỬ DỤNG, CHƯA BAO GỒM ẮC QUY

    THÔNG TIN THAY THẾ ẮC QUY CHO UPS (BATTERY REPLACEMENT)
    Tên, số lượng bộ ắc quy lắp mặc định
    (Replacement battery cartridge)
    APCRBC125
    x 01
    Bộ sạc & Tổ ắc quy lắp mặc định
    (UPS charger & Internal battery pack)
    12VDC/ 7W
    =1x 1x 12Vx WP1224W
    =73VAh capacity
    Tủ ắc quy mở rộng
    (External extended battery cabinet)
    Thời gian sạc lại
    (Typical recharge time)
    10 giờ
    Ắc quy khuyến nghị thay thế cho UPS
    (Recommend battery replacement)
    WP1224W
    Thông số kỹ thuật

    Output

    Output Power Capacity
    390 Watts / 650 VA
    Max Configurable Power
    390 Watts / 650 VA
    Nominal Output Voltage
    230V
    Output Frequency (sync to mains)
    47 - 63 Hz
    Topology
    Line Interactive
    Waveform Type
    Stepped approximation to a sinewave
    Output Connections
    (3) IEC 320 C13 (Battery Backup) IEC 320 C13

    Input

    Nominal Input Voltage
    230V
    Input Frequency
    50/60 Hz +/- 3 Hz (auto sensing)
    Input Connections
    IEC-320 C14
    Cord Length
    1.83 meters

    Batteries & Runtime

    Battery Type
    Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
    Typical recharge time
    10 hour(s)
    RBC™ Quantity
    1
    Runtime Graph
    This graph is based on actual measured runtime data. All measurements were taken with new, fully charged batteries and a balanced resistive load (PF = 1.0). Actual runtimes may vary from the values of this graph. Actual runtimes are dependent on several variables including battery age, battery charge level, environmental conditions and characteristics of the connected load.

    Communications & Management

    Audible Alarm
    Alarm when on battery : distinctive low battery alarm

    Surge Protection and Filtering

    Surge energy rating
    240 Joules

    Physical

    Maximum Height
    185.00 mm
    Maximum Width
    115.00 mm
    Maximum Depth
    213.00 mm
    Net Weight
    4.90 KG
    Shipping Weight
    5.50 KG
    Shipping Height
    257.00 mm
    Shipping Width
    190.00 mm
    Shipping Depth
    291.00 mm
    Master Carton Units
    1.00
    Color
    Black
    SCC Codes
    0073130426979 3
    Units per Pallet
    100.00

    Environmental

    Operating Environment
    0 - 40 °C
    Operating Relative Humidity
    0 - 95%
    Operating Elevation
    0-3000 meters
    Storage Temperature
    -15 - 45 °C
    Storage Relative Humidity
    0 - 95%
    Storage Elevation
    0-15000 meters

    Conformance

    Standard Warranty
    2 years repair or replace

    Sustainable Offer Status

    RoHS
    Compliant
    REACH
    REACH: Contains No SVHCs
    PEP
    Available in Documentation tab
    EOLI
    Available in Documentation tab
